XTOOL EZ300 Four System Diagnostic Tool With TPMS And Oil Light Reset Tool

XTOOL EZ300 is a high-end and new style auto diagnostic device developed by XTOOL based on Android system. Its open source Android operating system provides fast boot-up and multitasking. EZ300 provides engine, ABS, SRS, transmission and TPMS diagnosis for most US, Asian and European makes.

XTOOL EZ300

1.SD Card Port: up to 32GB extension SD card
2.HDMI Port: Compatible with HDMI
3.Micro USB: Battery charge or data synchronization with PC.
4.Audio Port: For headphone
5.Power Button: Power on or off

XTOOL EZ300

1. Power Indicator: it turns green when power is on.
2. Bluetooth Indicator: it turns red when Bluetooth is not connected; it turns blue when Bluetooth is connected successfully.
3. Vehicle Indicator: When VCI box is connected with vehicle successfully, it turns green.

Features:
*Easy registration with EZ300 connected to WIFI
*Wireless diagnosis via Bluetooth
*One-click software update via WIFI
*Remote access
*Diagnosis reports in PDF file
*Record and playback live data
*7 inch multi-touch screen
*On-board battery
*Extensive vehicle coverage for most US, Asian and European vehicle makes

 Easy registration with EZ300 connected to WIFI. Don’t bother to use PC for registration.

Wireless diagnosis via ultra fast Bluetooth technology

One-click update via WIFI. Get the latest software whenever you want! Never miss the update with pop-up update reminder!

Remote access, which is perfect for training, demonstration and even remote diagnosis.

Diagnosis reports in PDF file. Print out the diagnosis report and show it to car owners when they come and fetch their cars. They will be really happy knowing what kinds of problems have been fixed for their cars.

Extensive vehicle coverage for most US, Asian and European vehicle makes American: GM, Chrysler, Ford, Chevrolet, Hummer, Cadillac, Saturn

Europe:Volvo, Skoda, Land rover, Jaguar, Ford, Seat, Renault, Peugeot, Opel, Vauxhall, Fiat, Citroen, BMW, Mercedes, AUDI, VW, Porsche, MayBach, Rolls-Royce, Mini Cooper, Smart, Lamborghini, Bugatti, Abarth, VW etc ..
Asia:Acura, Honda, Infiniti, Isuzu, Lexus, Mitsubishi, Nissan, Suzuki, Kia, Toyota, Hyundai, Mazda, Daihatsu, Daewoo, Scion, Holden, AU Ford and more…

Four System Diagnosis:Engine, ABS, SRS, Transmission and TPMS

Basic Function: read fault codes, clear fault codes, live data

Accurate live data in both Wave and Dashboard form

Operating System:  Android 4.4.4
Memory:      1GB RAM,16GB Flash
CPU         Quad Core, 1.3 GHz
Display      7 Inch IPS 5-Point Multi-touch Screen with 1024×600P Resolution
Sensors:     Gravity Sensor, Light Sensor
Input/Output:    Microphone, Dual Speakers, 3.5 mm headset jack, Mini HDMI Port, 2.0USBPort, TF Card Port
Battery:      2400mAh, 3.7V
WIFI        WIFI 2.4Ghz
Bluetooth    100 Meters
Power Voltage:     3.7V
Power Consumption:  4W
Operating Temperature:   -20 to 50℃(-4 to 126℉)
Humidity:       <90%
Dimension:      (L*W*H): 208*140*15.5mm

Package Including:
1pcs X OBD II-16
1pcs X Main Cable
1pcs X EZ300 Tablet
1pcs X VCI Box
1pcs X Charger for Tablet
1pcs X US Power Adapter
1pcs X EU  Power Adapter
1pcs X Micro USB Cable
1pcs X Certificate of Quality
1pcs X Packing List
1pcs X User Manual
1pcs X Carton box
